Now fully upgraded and revised internally and externally featuring weight optimzation to lighten the overall weight without loss of strength and rigidty. Stamped steel side panels now replaced with CNC Aluminium. Top ventiation enhanced to a mesh providing improved air flow. New High speed Front USB 3.2 Gen 2 type C connector to support up to 10Gbps transfer speed.
Also coming soon custom - branded optional set of side panels and doors. Have your container case feature your unique brand design or company logo. Contact us for more details on this option.
Component support
Motherboard: Mini ITX 170x170mm
Power supply support: SFX or SFX-L
Supports:
Max GPU size: 340*165*68
Max CPU cooler 67mm
Supports one 120mm system fan
Riser cable Included
| Specification | |
|---|---|
| Volume |
11.6L |
| Width | 170mm |
| Height | 189mm |
| Depth | 360mm |
| aMax GPU Length x Height x Width | 340 x 165 x 68mm |
| Max CPU cooler height | 67mm |
| Power supply options (not included) | SFX, SFX-L |
| External panels | 1.5mm Aluminium Alloy outer shell |
| Internal mounting frame | 1/1.5/2mm thick SPCC steel powder coated |
| Top panel switches | On/Off. USB3.2 Gen2 (type C), Headphone jack 3.5mm |
| Riser Cable INCLUDED | PCI-E 4.0 compatible riser cable included |
| Fan support | Single Bottom 120mm (fan not incldued) |
| Drive bay support | Can support up to 4x2.5"SSD - 2 |
| PSU socket extender lead |
1m mains lead with 90° C13 connector to C14 socket included. You will need your particular counties mains lead with suitable C13 kettle plug (sometimes included with power supplies) as this is not included. |
| Weight | 2.5KG |
